Stylish Design 2 Pipe Fan Coil System Office Center Air Controlling Thermostat With Keycard HTW-WF11-FC
Stylish Design 2 Pipe Fan Coil System Office Center Air Controlling Thermostat With Keycard HTW-WF11-FC Stylish Design 2 Pipe Fan Coil System Office Center Air Controlling Thermostat With Keycard HTW-WF11-FC Stylish Design 2 Pipe Fan Coil System Office Center Air Controlling Thermostat With Keycard HTW-WF11-FC Stylish Design 2 Pipe Fan Coil System Office Center Air Controlling Thermostat With Keycard HTW-WF11-FC Stylish Design 2 Pipe Fan Coil System Office Center Air Controlling Thermostat With Keycard HTW-WF11-FC

Stylish Design 2 Pipe Fan Coil System Office Center Air Controlling Thermostat With Keycard HTW-WF11-FC

Product ID : HTW-WF11-FC-2K
Product Tags : Fan coil thermostat
Product Attributes :

HTW-WF11-FC-2/4 series standalone fan coil thermostat is to control fan coil system, with 3-speed fan and water based valve outputs, which is widely used in these environment like Homes, Residential buildings,Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.

Product Description
Product Description



Stylish Design 2 Pipe Fan Coil System Office Center Air Controlling Thermostat With Keycard HTW-WF11-FC
Power supply
95~240Vac,50/60Hz
Sensor
NT3950,10K
Current Load
Fan Relay 5A(3A-inductive)
Temperature Accuracy
±0.5℃ or ±1F
Storage Temp.
-5~45℃
Display Temp.Range
5~99℃
Power  Consumption
<1.5W
Timing Error
<1%
Housing Material
PC+ABS(Fireproof)
Installation Box
EU or Standard Electric Box
Wires on Terminals
Wire 2*1.5 * mm² or 1*2.5  * mm²
Protection Class
IP20
Operating Bottons
Capacitive Touch Buttons



>>General
HTW-WF11-FC-2/4 series standalone fan coil thermostat is to control fan coil system, with 3-speed fan and water based valve outputs, which is widely used in these environment like Homes, Residential buildings,Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.

>>Features

* Snap-In Easy Installation
* Fit for EU & Standard Junction Electric Box
* Fashion Scence of Science and Technology
* Weekly Programmable
* Cooling only/Heating or Cooling mode
