Noise-Free Controlling Thermostat split thermostat for Hotel occupancy system
Noise-Free Controlling Thermostat split thermostat for Hotel occupancy system Noise-Free Controlling Thermostat split thermostat for Hotel occupancy system Noise-Free Controlling Thermostat split thermostat for Hotel occupancy system Noise-Free Controlling Thermostat split thermostat for Hotel occupancy system Noise-Free Controlling Thermostat split thermostat for Hotel occupancy system

Noise-Free Controlling Thermostat split thermostat for Hotel occupancy system

Product ID : HTW-61-EW001-B
Product Tags : hotel thermostat
Product Attributes :

HTW-61-EW001-B is a Touch Screen Split Thermostat Noise-Free Hotel Room Climate Controller application for water installations with fan coils. It is designed as a stand-alone device to operate the fan coil unit of a zone and includes a set of functions for zone occupancy and window position based climate control.

Product Description
Product Description

>> General

Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat consists of 2 parts:
HTW-61-EW001-B control panel dispalay part
HTW-61-EW001-RM relay module part
These 2 parts conected with 4-pin data wire max. up to 30m, which makes it possible to install the relay module part to a remote place apart from the room, for a noise-free purpose.
HTW-61-EW001-B is a Touch Screen Split Thermostat Noise-Free Hotel Room Climate Controller application for water installations with fan coils. It is designed as a stand-alone device to operate the fan coil unit of a zone and includes a set of functions for zone occupancy and window position based climate control.
A high level of comfort and appropriate climate control to ensure maximum energy savings are thus provided.
The device is a compact unit that includes a large backlit display screen, a built in temperature sensor, pushbuttons on the front panel, and inputs and outputs built on split remote relay module for room control.
This Split Thermostat Climate Controller includes two parts:
HTW-61-EW001-B
HTW-61-EW001-RM
These two parts are communicated via 4-wire connections:
-GND
-12V
-TXD
-RXD
It provides a totally Noise-Free application due to its remoted relay module.



>> Feature

-Touch Screen Display
-60mm Standard Installation Hole Distance
- Wide, blue backlit LCD, 65 × 59 (mm)
- Front panel built in pushbuttons: +T/-T/Fan speed/On-Off
- Front panel built in temperature sensor
- Change Over-HEAT/COOL
- Configurable for 2 pipe / 4 pipe systems
- Selectable temperature units (ºC/ºF)
- Configurable max/min/economy temperature setpoints
- Keycard switch contact occupancy monitoring for energy saving
- Configurable keycard switch input: keycard switch/lighting
- Configurable fan coil: 3 speeds / 1 speed
- Speed 1 configurable as blocked or unblocked on zero demand
- Economy mode Heat/Cool temperature setpoint Heat/Cool dead band
- Delayed switching to Economy when card is removed
- Automatic device startup after loss of power
- Configurable NO/NC valve outputs
- Connfigurable anti-humidity frequency:10/30,5/30,5/60
- Noise-Free application

Device Inputs
Device Outputs
1 Digital, keycard switch contact / lighting auxiliary contact
3 Relays, fan coil speed (I,II,III)
1 Digital, window contact
1 Relay, chilled water valve
1 Analog, ambient temperature external sensor
1 Auxiliary relay (hot water valve on 4 pipe systems / lighting on 2 pipe systems)
1 Temperature sensor, built in on device front panel
1 Auxiliary relay for lamp



>>Wiring Diagram

If a magnetic window contact switch is connected to the terminals 12-13, when the contact is open, the output S1 will disconnect after 1min, until closing window contact again.
