2 Way DN20 Electric Actuator Control Motorized Ball Valve
2 Way DN20 Electric Actuator Control Motorized Ball Valve 2 Way DN20 Electric Actuator Control Motorized Ball Valve 2 Way DN20 Electric Actuator Control Motorized Ball Valve 2 Way DN20 Electric Actuator Control Motorized Ball Valve 2 Way DN20 Electric Actuator Control Motorized Ball Valve

2 Way DN20 Electric Actuator Control Motorized Ball Valve

Product ID : HTW-EG
Product Tags :
Product Attributes :

HTW-EG200 Series Motorized Ball Valves are used to control the on/off of heat/cool water air-conditioning system pipe to control the room temperature.  The valve is driven by synchronous motor.  The motor connects with room thermostats by the terminal of common, open and close.  By sampling and dealing with the site data, the thermostats send control signal to open/close the motor of ball valve.  Then the heat/cool water enters into fan coil unit to supply the heat or cool air.  When the room temperature reaches the set-point, thermostat will send a signal to cut off the ball valve and make it on the best status. Then the room temperature will keep in the comfortable range.

Valve thread size: G1/2、G3/4、G1、G1.1/4

Thread connection. Valve body could be installed first.  Simple wiring. The actuator could be installed near to the wall.


Product Description


>> General

HTW-EG200 Series Motorized Ball Valves are used to control the on/off of heat/cool water air-conditioning system pipe to control the room temperature.  The valve is driven by synchronous motor.  The motor connects with room thermostats by the terminal of common, open and close.  By sampling and dealing with the site data, the thermostats send control signal to open/close the motor of ball valve.  Then the heat/cool water enters into fan coil unit to supply the heat or cool air.  When the room temperature reaches the set-point, thermostat will send a signal to cut off the ball valve and make it on the best status. Then the room temperature will keep in the comfortable range.

Valve thread size: G1/2、G3/4、G1、G1.1/4

Thread connection. Valve body could be installed first.  Simple wiring. The actuator could be installed near to the wall.

>>Technical parameters

• Driving voltage:220VAC (12V, 24V, 110VAC optional)

• Power consumption:5VA (only during course of open and close)

• Pressure-bearing of valve body:1.6MPa
• Allowance pressure:≤0.6MPa
• Applicable medium:cool water, hot water and low pressure steam (≤0.4MPa)
• Open and close time:two-way 30s, three-way 57s.
• Temperature of applicable medium:1℃-130℃
• Applicable environment temperature:0℃-65℃
• Connection manner:ZG internal pipe thread (could be customized)



>>Wiring Diagram

Ball Valve HTW-EG-wiring.jpg

>>Model Comparison Table



>>Installation

>>Company Profile




>>Packing Information


>>Our Service

photobank (3).jpg

Customer Service

1. OEM & ODM service offered

2. sample's fee can be refunded after order reached 2000pcs

Warranty
1. Test the products one by one before delivery
2. We guarantee 18months from the date you get the goods,excludes damaged by human
3. If you can find out the problem and fix it easily, we will offer several components for service


>>FAQs

Q1:What is the unit price?
A.:The unit price varies according to different specific requirements, we are more than pleased to quote you the best price once get your specific application. e.g. W/O Modbus, W/O key-card, 2/4 pipe system, W/O customized programming...
Anyway, we are always ready to discuss details with you via Email.

Q2:What is the MOQ, small quantities accetaple?
A.: Commonly the MOQ for us is 500pcs, however, we also accept small quantities or Sample orders as starting.

Q3:How is your products' quality and warrenty?
A.:All of our products meet EU standards, samples are available for quality evaluation; all products are with 18 months warrenty.

Q4:Can I print my logo on the products, and customize my own designed packing?
A.:100% YES, but the order quantity shall be over MOQ, or else, extra costs will be charged.

Q5:Do you supply OEM or ODM?
A.:Yes, we have strong R&D sources and production ability, and already helping many international companies OEM/ODM cases with highly positive feedback.

Q6:Why should I buy products from your company?
A.:That's really a good question, Quality Products but with Competitive Price, Timely Delivery, Professional and Fast Reacton, ...
In a word, WE ARE DIFFERENT, why not just try from the Email...
