Rs485 Modbus Wifi Thermostat Dual Sensor Ec Fan Controller Thermostat Hvac Hotowell FC08

Product ID : HTW-FC08-ECNW

Product Tags : Fan coil thermostat Room thermostat Wifi thermostat modbus thermostat

Product Attributes :

HTW-FC08-ECNW smart fan coil thermostat is designed with EC Fan + 1 cool valve + 1 heat valve + externals sensor + Keycard + Modbus +WiFi communication functions.

Product Description

Rs485 Modbus Wifi Thermostat Dual Sensor EC Fan Controller Thermostat Hvac Hotowell FC08

>> General

HTW-FC08-ECNW

HTW-FC08-ECNW smart fan coil thermostat is designed with EC Fan + 1 cool valve + 1 heat valve + externals sensor + Keycard + Modbus +WiFi communication functions. It is widely used in environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices, etc. to maintain an ideal room temperature.

>> Wiring

>> Specification

Power Supply	95~240Vac, 50/60Hz	Sensor	NTC3950, 10K
Current Load	EC Fan DC 0-10V	Temperature Accuracy	±0.5°C or ±1℉
Current Load	Valve Relay 3A (1A-inductive)	Set-Point Range	5~35°C
Storage Temp.	-5 ~ 45 °C	Display Temp. Range	5~99°C
Power Consumption	< 1.5W	Timing Error	< 1%
Housing Material	PC +ABS (Fireproof)	Installation Box	EU or Standard Electric Box
