Wireless Programmable Room Thermostat
●5+1+1 weekly set-point temperature programmable
●Room temp. And set-point temp. Display
●Wireless communication
●Heating state display
●5 buttons: PRG(programmable) button, Mode Select button, ON/OFF button, Temp.¶meters setting
●Smartphone control, convenient and energy saving
General of Wireless Thermostat and Receiver
How does the wireless programmable room's heating thermostat work? Take Hotowell HTW-WKT19-WF wireless boiler thermostat as an example. We believe everyone should be familiar with the water floor heating temperature control system which is popular in Europe. In the water floor heating system, the function of the thermostat is to control the boiler, water valve, or manifold actuator. Wireless boiler heating thermostat is not an all-in-one model, which consists of receiver and sender, RF wireless signal is used between them. Programmable thermostats have a weekly programming function, which can set different temperatures for 4 periods each day. For example, every morning at 7:00-8:30, set to 18-22 degrees; 8:30-17:30 work hours(if users work in an office but not at home), the temperature can be set to around 10-12 degrees; 17:30-22:00, set around 20 degrees as families are back home; 22: 00-7: 00 is bedtime, set to 18 degrees. The temperature schedule can be adjusted according to everyone's habits.
Video Description of Boiler Gas Heating Room Thermostat
Operation is similar to HTW-31-WKT13-WF model, shown as below video:
Specification of Battery Power Thermostat
|
Sender power supply |
2*AAA batteries |
Accuracy of Temp. |
±0.5°C |
|
Receiver Load current |
230Vac/Max 10A |
Set-Point Temp. Range |
5°C ~35°C |
|
Ambient temperature |
0~50℃ |
Built-in Sensor |
NTC 10K, 3950ohms |
|
Relative Humidity |
85% |
Protection Class |
IP30 |
|
Housing of thermostat |
ABS ~ UL94-5 fireproof plastic |
||
Default Set-point Temperature Programmable Setting
|
Periods |
Set-point temperature Programmable Setting |
||
|
12345(Mon.~Fri.) |
6(Sat.) |
7(Sun.) |
|
|
P1: 7:30 am |
25℃ |
23℃ |
23℃ |
|
P2: 9:00 am |
16℃ |
23℃ |
23℃ |
|
P3: 17:30 pm |
24℃ |
23℃ |
23℃ |
|
P4: 23:30 pm |
19℃ |
19℃ |
22℃ |
