Smart Tuya Thermostat Modbus Fan Coil Thermostat with LED Matrix Lighting Screen
Smart Tuya Thermostat Modbus Fan Coil Thermostat with LED Matrix Lighting Screen Smart Tuya Thermostat Modbus Fan Coil Thermostat with LED Matrix Lighting Screen Smart Tuya Thermostat Modbus Fan Coil Thermostat with LED Matrix Lighting Screen Smart Tuya Thermostat Modbus Fan Coil Thermostat with LED Matrix Lighting Screen Smart Tuya Thermostat Modbus Fan Coil Thermostat with LED Matrix Lighting Screen

Smart Tuya Thermostat Modbus Fan Coil Thermostat with LED Matrix Lighting Screen

Product ID : HTW-WF03-FC
Product Attributes :

HTW-WF03-FC series Smart Wifi fan coil thermostat is widely used in these environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.

Product Description
Product Description
Smart Tuya Thermostat Modbus Fan Coil Thermostat with LED Matrix Lighting Screen
>> General
HTW-WF03-FC series Smart Wifi fan coil thermostat is widely used in these environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.

>> Specifications

Power Supply
95~240Vac, 50/60Hz
Sensor
NTC3950, 10K
Current Load
Fan Relay 5A(3A-inductive)
Temperature Accuracy
±0.5°C or ±1℉
Valve Relay 3A(1A-inductive)
Set-Point Range
5~35°C
Storage Temp.
-5 ~ 45 °C
Display Temp. Range
5 ~ 99°C
Power Consumption
< 1.5W
Timing Error
< 1%
Housing Material
PC +ABS ( Fireproof)
Installation Box
EU or Standard Electric Box
Wires on Terminals
Wire 2 x 1.5 mm2 or 1 x 2.5 mm2
Protection Class
IP20
Operating Buttons
Capacitive Touch Buttons

>> Ordering Guide

>> Details
