Voltage Customization SPST or SPDT FCU Motorized Zone Valve Actuator and Valve Body

Product ID : HTW-V61

Product Tags : Motorized Zone Valve

Product Attributes :

HTW-V61 series motorized valves(3-wire) are used to control the flow of hot water, chill water in heating, cooling or air-conditioning applications, so as to control room temperature indirectly.

Product Description

Voltage Customization SPST or SPDT FCU Motorized Zone Valve Actuator and Valve Body

>> General

HTW-V61 series motorized valves(3-wire) are used to control the flow of hot water, chill water in heating, cooling or air-conditioning applications, so as to control room temperature indirectly. It consists of Actuator and Valve Body. The room temperature could be controlled in the set-point through turn-on or turn-off of valve.

Specification

Model Number	HTW-V61
Type	Check valves
Customized support	OEM, ODM
Warranty	2 years
Consumption	5W
Drive style	Bi-direction reversible motor drive
Cooperate time	the valve open within 16s at 60HZ
N.W.(Kg)-Actuator	0.35
Medium	Cool/hot water
Liquid temperature	1~95°C
Pressure(MPa)	2-2.5Mpa
Environment temperature	0~65°C the max relative humidity, non-condensing
Storage temperature	-20~65°C the max relative humidity, non-condensing
