240V IP65 Paddle Thermal Flow Switch Water Pump Heat Pump Water Flow Switch
240V IP65 Paddle Thermal Flow Switch Water Pump Heat Pump Water Flow Switch 240V IP65 Paddle Thermal Flow Switch Water Pump Heat Pump Water Flow Switch 240V IP65 Paddle Thermal Flow Switch Water Pump Heat Pump Water Flow Switch 240V IP65 Paddle Thermal Flow Switch Water Pump Heat Pump Water Flow Switch 240V IP65 Paddle Thermal Flow Switch Water Pump Heat Pump Water Flow Switch

240V IP65 Paddle Thermal Flow Switch Water Pump Heat Pump Water Flow Switch

Product ID : HTW-AFS-B
Product Tags :
Product Attributes :

Features:
● Flow control of water and normal media

● Renovated SPDT micro switch ensures the reliable switch function

● 15(8A) 250VAC switch rating

● IP65, class I enclosur

● Brass/S.S Material optional


Product Description

 >> Features

● Flow control of water and normal media

● Renovated SPDT micro switch ensures the reliable switch function
● 15(8A) 250VAC switch rating
● IP65, class I enclosure

 >>Specification

Type of operation                         On/Off, single-stage, micro switch

Output                                          SPDT  15(8A)  24/250Vac

Flow rates                                    See flow rate table

Flow rate setting adjustment       Internal srew

Sensing element                           Paddle

Liquid applications                        Hot, chilled, well, pool and sea water,

                                                     Brine or ethylene glycol

Parts material in contact with fluid    Brass

Paddle material                             Stainless steel



Liquid temperature                         -20C-120C

Permissible ambient temperature   -40C-85C

Permissible ambient humidity         10…90% RH, non-condensing

Cable entry                                       M18

Housing                                          Galvanized Steel Plate, ABS or PC cover

Protection                                      IP65

Color                                              White

Weight                                            1.0Kg
