Programmable RF Wireless Radio Room Thermostat for boiler heating
Weekly programmable wireless room thermostat-HTW-31-WKT13 is designed to be used with electric, gas or oil heating control system or cooling system.
This surface-mounted radio thermostat has been developed to be able to switch electric and conventional heating systems on and off using a set temperature and time.
Programmable Wireless Radio Room Thermostat-HTW-31-WKT13.pdf
>> General
Weekly programmable wireless room thermostat-HTW-31-WKT13 is designed to be used with electric, gas or oil heating control system or cooling system.
This surface-mounted radio thermostat has been developed to be able to switch electric and conventional heating systems on and off using a set temperature and time.
>> Features
• Easy household installation to detect and control the temperature of an area of the user's choice
• More convenient to change the battery .
• Signal transmission distance up to 100m
• Clear intuitive LCD display
• Displays the set point + room temperature + time simultaneously
• 4 periods of each day programmable(5+1+1)
• Optional temperature display of Celsius or Fahrenheit scale
• Both vacation mold and hold duration mode available for comfort and energy saving
• Separate 5-day (weekday) and 1-day/1-day (Saturday/Sunday programming with four separate time/temperature periods per day)
• Supplied with a wall-fixing frame, base and a very compact receiver (surface-mounted).
>> Technical parameters
• Power source :2 AA size 1.5V alkaline battery
• Receiver operating voltage: 230 VAC, 50/60 Hz
• Max. load: 250 VAC/10 A.
• Wireless frequency band: 868 MHz/433Mhz optional
• Wireless transmitte range:100m in the open air
• Accuracy:0.5°C
• Receiver switch contacts: NO and NC.
• Temperature settings: 5°C ~ 35°C, 0.5°C increments.
• Thermostat dimensions: Surface mounted, 135mm x 87.5 mm x 23.2mm.
• Receiver dimensions: Surface mounted, 114mm x 86 mm x30mm.
>> Dimenstions
