WF11 Smart Wifi 16A Electric Underfloor Heating Digital Thermostat With Temperature Sensor
WF11 Smart Wifi 16A Electric Underfloor Heating Digital Thermostat With Temperature Sensor WF11 Smart Wifi 16A Electric Underfloor Heating Digital Thermostat With Temperature Sensor WF11 Smart Wifi 16A Electric Underfloor Heating Digital Thermostat With Temperature Sensor WF11 Smart Wifi 16A Electric Underfloor Heating Digital Thermostat With Temperature Sensor WF11 Smart Wifi 16A Electric Underfloor Heating Digital Thermostat With Temperature Sensor

WF11 Smart Wifi 16A Electric Underfloor Heating Digital Thermostat With Temperature Sensor

Product ID : HTW-WF11-16A3
Product Attributes :

HTW-WF11 series Wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.

Product Description

Product Description

WF11 Smart Wifi 16A Electric Underfloor Heating Digital Thermostat With Temperature Sensor

>> General

HTW-WF11 series Wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.



>> Features

>> Technical Parameter



HTW-WF11-**
Power Supply 95~240Vac, 50/60Hz
Current Load 3A(-3A, -NV application) ; 16A(-16A application)
Storage Temp. -5 ~ 45 °C
Power Consumption < 1.5W
Housing Material PC +ABS ( Fireproof)
Wires on Terminals Wire 2 x 1.5 mm2 or 1 x 2.5 mm2
Protection Class IP20
Sensor NTC3950, 10K
Temperature Accuracy ±0.5°C or ±1℉
Set-Point Range 5~35°C
Display Temp. Range 5 ~ 99°C
Timing Error < 1%
Installation Box
EU or Standard Electric Box
Operating Buttons Capacitive Touch Buttons

>>Typical wiring disgram
