WF17 Wifi TFT Colorful Knob Screen Room Smart Underfloor Water Heating Thermostat
Product ID : HTW-WF17
Product Attributes :
The HTW-WF17 Series thermostat has been developed to control electric underfloor, water heating or water/ gas boiler systems. These units are designed for use in commercial, industrial, civil and domestic properties.
Product Description
Product Description
WF17 Wifi TFT Colorful Knob Screen Room Smart Underfloor Water Heating Thermostat
>> General
The HTW-WF17 Series thermostat has been developed to control electric underfloor, water heating or water/ gas boiler systems. These units are designed for use in commercial, industrial, civil and domestic properties.
>> Features
>> Technical Parameter
| HTW-WF17-** | |
| Power Supply | 95~240Vac, 50/60Hz |
| Current Load | 5A (water heating, gas boiler), 16A (electric heating) |
| Storage Temp. | -5 ~ 45 °C |
| Power Consumption | < 1.5W |
| Housing Material | PC +ABS ( Fireproof) |
| Wires on Terminals | Wire 2 x 1.5 mm2 or 1 x 2.5 mm2 |
| Protection Class | IP20 |
| Sensor | NTC3950, 10K |
| Temperature Accuracy | ±0.5°C or ±1℉ |
| Set-Point Range | 5~35°C |
| Display Temp. Range | 5 ~ 99°C |
| Timing Error | < 1% |
|
Installation Box
|
EU or Standard Electric Box |
| Operating Buttons | Capacitive Touch Buttons |
