EC FAN 2 pipe thermostat Hot Sale Wifi Temperature Controller Modbus RTU RS485 thermostat

Product ID : HTW-61-DA

Product Tags :

Product Attributes :

This series thermostat application is designed for room climate control at hotels, offices and homes with water and fan coil installations.

-3D1D includes 3 load digital ON/OFF fan speed outputs and 1 load digital ON/OFF valve output;

-1A1D includes 1 load analogue EC fan motor output and 1 load digital ON/OFF valve output;

-1A1A includes 1 load analogue EC fan motor output and 1 load analogue valve output;

The device includes a built in temperature sensor on its front panel for room temperature measurement, and features an advanced control algorithm for fan coil speed and valve position control.

The device includes a simple configuration menu that allows configuring up to 28 parameters. The unit can thus be adapted to the requirements of each installation.

Product Description

Product Description


Ac system thermostat digital display FCU thermostat for EC fan


>> General

This series thermostat application is designed for room climate control at hotels, offices and homes with water and fan coil installations.
-3D1D includes 3 load digital ON/OFF fan speed outputs and 1 load digital ON/OFF valve output; -1A1D includes 1 load analogue EC fan motor output and 1 load digital ON/OFF valve output; -1A1A includes 1 load analogue EC fan motor output and 1 load analogue valve output; The device includes a built in temperature sensor on its front panel for room temperature measurement, and features an advanced control algorithm for fan coil speed and valve position control. The device includes a simple configuration menu that allows configuring up to 28 parameters. The unit can thus be adapted to the requirements of each installation
