Heat Pump System Room Thermostat WiFi Tuya APP Control
Product ID : HTW-MT08
Product Attributes :
HTW-MT08 Series Single Multi-Stage Digital Heat Pump Thermostat is a device for indoor temperature control. It is mainly applied to heat pump system for heating/cooling, the device is of high reliability and practicability, and it can support up to 3H/2C system. This model is Max. 2H2C for conventional System or Max. 3H/2C for Heap Pump System.
Product Description
Heat Pump System Room Thermostat WiFi Tuya APP Control
>> General
This thermostat is compatible with the following systems:
• Gas, oil, Propane or electric furnace
• Central air conditioner
• Geo Thermal / Hot water system with or without pump
• Heat only/Cool only/Auto/Emer/Off modes configurable
• Central heating and cooling system
• Heat pump with auxiliary/backup heat
• Forced Air / In-Floor Radiant / Radiator system
| Power Supply | 24VDC/AC +10% . |
| Current Load | 1A (Inductive) 3A (Resistance) |
| Sensor | NTC3950, 10K |
| Set Temp. Range | 41-95 °F (5~35°C) |
| Accuracy | 1 °F (0.5°C) |
| Display Temp. Range | 41~95 °F (5~35°C) |
| Ambient Temp. | 32~113 °F (0~45°C) |
| Ambient Humidity | 5~1 95%RH(Non Condensing) |
| Storage Temp. | 23~113°F (-5~45°C) |
| Timing Error | < 1% |
| Power Consumption | <1.5W |
| Shell Material | PC+ ABS(Fireproof) |
| Available Installation 1 | Wall mounted |
| Available Installation 2 | Distance of 62+ 5mm(Europe, China and Japan) |
| Available Installation 3 | Hole Distance of 86+3mm(USA and Italy etc) |
| Wire Terminals | Wire 2x1.5mm2 or 1x2.5mm2 |
| Protection Class | IP20 |
| Buttons | Capactive Touch Buttons |
