HVAC System Central Controller Smart Programmable Fan Coil Thermostat with Modbus Option
HVAC System Central Controller Smart Programmable Fan Coil Thermostat with Modbus Option HVAC System Central Controller Smart Programmable Fan Coil Thermostat with Modbus Option HVAC System Central Controller Smart Programmable Fan Coil Thermostat with Modbus Option HVAC System Central Controller Smart Programmable Fan Coil Thermostat with Modbus Option HVAC System Central Controller Smart Programmable Fan Coil Thermostat with Modbus Option

HVAC System Central Controller Smart Programmable Fan Coil Thermostat with Modbus Option

Product ID : HTW-EB-FC
Product Tags : Fan coil thermostat
Product Attributes :

HTW-EB-FC series Wi-Fi thermostat is widely used in these environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.

Product Description
Description
HVAC System Central Controller Smart Programmable Fan Coil Thermostat with Modbus Option



>> General

HTW-EB-FC series Wi-Fi thermostat is widely used in these environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.



>> Features



1/ 17 Mainstreaming Languages synchronize in APP( English, Spanish, Russian, Hungarian, Turkey, Hebrew, German, Italian, Japanese, French, Poland, simplified Chinese, traditional Chinese, Holland, Portuguese, Vietnamese, Arabic, Korean) 2/ Snap-In Easy Installation 3/ Fit for EU & Standard Junction Electric Box 4/ Easily Work with Amazon Echo, Google Home, Tmall Genie 5/ Group Control in 1 App 6/ Fashion Sense of Science and Technology



>> Ordering Guide

>> Specifications

Power Supply
95~240Vac, 50/60Hz
Sensor
NTC3950, 10K

Current Load
Fan Relay 5A(3A-inductive)
Temperature Accuracy
±0.5°C or ±1℉
Valve Relay 3A(1A-inductive)
Set-Point Range
5~35°C
Storage Temp.
-5 ~ 45 °C
Display Temp. Range
5 ~ 99°C
Power Consumption
< 1.5W
Timing Error
< 1%
Housing Material
PC +ABS ( Fireproof)
Installation Box
EU or Standard Electric Box
Wires on Terminals
Wire 2 x 1.5 mm2 or 1 x 2.5 mm2
Protection Class
IP20
Operating Buttons
Capacitive Touch Buttons

>> Dimensions and Display

Certifications
Packing & Shipping

Online Inquiry
