Modbus Fan Coil 2/4 pipes System Thermostat With Keycard Input

Product ID : HTW-WF11-FC-2.4KN

Product Tags :

Product Attributes :

HTW-WF11-FC series Modbus fan coil thermostat is designed to control 4 pipe Fan Coil Unit system, withoutputs of 3 fan speed and 1 cooling valve and 1 heating valve, with remote setback(keycard) input andModbus communication. It is widely used in these environment like Homes, Residential buildings, Schools,Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.

Product Description

Modbus Fan Coil 2/4 pipes System Thermostat With Keycard Input

>>General HTW-WF11-FC series Modbus fan coil thermostat is designed to control 4 pipe Fan Coil Unit system, withoutputs of 3 fan speed and 1 cooling valve and 1 heating valve, with remote setback(keycard) input andModbus communication. It is widely used in these environment like Homes, Residential buildings, Schools,Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.

>>Features

* Snap-In Easy Installation
* Fit for EU & Standard Junction Electric Box
* Fashion Scense of Science and Technology
* Remote Setback(Keycard)
* Mobus Communication

Specification

Power supply	95~240Vac,50/60Hz	Sensor	NT3950,10K
Current Load	Fan Relay 5A(3A-inductive)	Temperature Accuracy	±0.5℃ or ±1F
Storage Temp.	-5~45℃	Display Temp.Range	5~99℃
Power Consumption	<1.5W	Timing Error	<1%
Housing Material	PC+ABS(Fireproof)	Installation Box	EU or Standard Electric Box
Wires on Terminals	Wire 21.5 mm² or 12.5 mm²
Protection Class	IP20	Operating Bottons	Capacitive Touch Buttons
