220v Electric thermal valve Actuator for underfloor heating system
HTW-TV02-VA Thermal Valve Actuator is designed to control the open/close of the pipe of chilled/hot water for HVAC system so as to control the indoor temperature and maintain a thermal room temperature.
It is installed on the chilled/hot water pipe, and the valve is controlled to open or close via the signal send from thermostat. The thermostat sends a signal to open the thermal valve to cool/ heat the room via heat exchange from the cooling/heating media, like chilled/heating water.
>> General
HTW-TV02-VA Thermal Valve Actuator is designed to control the open/close of the pipe of chilled/hot water for HVAC system so as to control the indoor temperature and maintain a thermal room temperature.
It is installed on the chilled/hot water pipe, and the valve is controlled to open or close via the signal send from thermostat. The thermostat sends a signal to open the thermal valve to cool/ heat the room via heat exchange from the cooling/heating media, like chilled/heating water.
2 models for options:
HTW-TV02-VAC
HTW-TV02-VAO
HTW-TV02-VAC fits for normally closed valve bodies HTW-TV02-VBC series
HTW-TV02-VAO fits for normally open valve bodies HTW-TV02-VBO series
>> Specification
| Housing | Material | PA6110 | |
| Color | White | ||
| Control Element | Electro-thermal Wax Sensor | ||
| Working Force Intensity (F) & Direction | 80n≤ f＜130n; direction: downward | ||
| Connector | For HTW-TV02-VB1/ VB2 Valves | M30x1.5 | |
| Working Ambient Temperature | -0.5℃~60℃ | ||
| First Fully Open | 5~6.5 minutes (at 25℃) | ||
| Protection Class | IP40 | ||
| Power Consumption | 1.1VA | ||
| Max. Impact Current | 24v | 1.2A | |
| 110v | 0.9A | ||
| 220v/230v | 0.7A | ||
| Lead Wire | 1M Length (2-Core) | ||
| Net Weight | 94g | ||
>> Dimensions
>> Valve Body
HTW-TV02-VB series valve body is designed for temperature control in the HVAC circumstance.
There are three-port type models:
--HTW-TV02-VB*-2**2 Way Valve Body
--HTW-TV02-VB-3**3 Way Valve Body
--HTW-TV02-VB-4**4 Way Valve Body
HTW-TV02-VB*-2** 2 Way Valve Body varies from 2 types as below:
--Normally close(N.C.) HTW-TV02-VBC-2**
For the normally close type valve, the actuator drives the piston to open the valve in a direct way and close it on an angle way.
--Normally open(N.O.) HTW-TV02-VBO-2**
For the normally open 2-way valve, the actuator drives to close it. Spring is used to return the piston.
These valve bodies feature condensed structure, reliability, and convenient installation.
>> Specification
| Materials | Valve body | Forging brass |
| Valve stem | Stainless steel (1cr18ni9) | |
| Spring | Stainless steel wire (1cr18ni9) | |
| Inner cover | Pbt | |
| Piston | Frpa-66 | |
| O-sealing- ring | Nitrile rubber | |
| Valve body rating pressure | 1.6mpa | |
| Stroke | 4.5 (mm) | |
| Max. Allowed flow speed | 3m/s | |
| Allowed liquid | Water, water + glycol | |
| Temperature | 5～95℃ | |
| Leakage | 0 (tight close-off on direct and angle way) | |
>> Model Description
| HTW-TV02-VB*- | C/O | 2002-3-4 | 2/3/4 port | 09 | A40 |
| Valve Body Code | N.C/N.O. | Valve Port Type | DN15/DN20 | Kvs Code | The distance of the Centers |
| (Only for the 4 Outlet Valve) | |||||
| Valve Body | C=Normally Closed O=Normally Open Only available in 2-way valve | 2—2-way 3—3-way 4—3-way, 4-outlet | 15=G1/2 20=G3/4 | 09—Kv=0.25 10—Kv=0.40 11—Kv=0.60 12—Kv=1.00 13—Kv=1.60 20—Kv=2.00 23—Kv=2.50 |
A35—35mm centers A40—40mm centers A50—50mm centers |
>> Installation
Before the installation, please make sure the pipe is clean (no soldering scraps), so the valve piston won’t be blocked, and the flow direction indicated on the valve body is correct. Actuator should be mounted above the valve body. We recommend using 3-way valve as mixing valve.
*2-way valve:
A→AB normally open or normally close
*3-way valve:
A→AB normally close B→AB normally open
Flow direction details please refer as below pictures
