2 Inch Motorized Ball Valve
2 Inch Motorized Ball Valve 2 Inch Motorized Ball Valve 2 Inch Motorized Ball Valve 2 Inch Motorized Ball Valve 2 Inch Motorized Ball Valve

2 Inch Motorized Ball Valve

Product ID : HTW-DH
Product Tags :
Product Attributes :

HTW-DH Series Motorized Ball Valves are used to control the on/off of heat/cool water air-conditioning system pipe to control the
room temperature. The valve is driven by synchronous motor. The motor connects with room thermostats by the terminal of common,
open and close. By sampling and dealing with the site data, the thermostats send control signal to open/close the
motor of ball valve. Then the heat/cool water enters into fan coil unit to supply the heat or cool air. When the room temperature
reaches the set-point, thermostat will send a signal to cut off the ball valve and make it on the best status. Then the room
temperature will keep in the comfortable range.
Valve thread size: G1/2、G3/4、G1、G1.1/4
Thread connection. Valve body could be installed first. Simple wiring. The actuator could be installed near to the wall.

Product Description

 >> General

HTW-DH Series Motorized Ball Valves are used to control the on/off of heat/cool water air-conditioning system pipe to control the room temperature. The valve is driven by synchronous motor. The motor connects with room thermostats by the terminal of common, open and close. By sampling and dealing with the site data, the thermostats send control signal to open/close the motor of ball valve. Then the heat/cool water enters into fan coil unit to supply the heat or cool air. When the room temperature reaches the set-point, thermostat will send a signal to cut off the ball valve and make it on the best status. Then the room temperature will keep in the comfortable range. Valve thread size: G1/2、G3/4、G1、G1.1/4 Thread connection. Valve body could be installed first. Simple wiring. The actuator could be installed near to the wall.

 >> Materials

* Valve Body: Hpb59-1 (Gilded with Nickle) ;
* Valve Seal: Stem: EPDM with double O-ring ;
* Ball: PTFE+EPDM with double O-ring;
* Actuator enclosure: PC+10GF;
* Actuator revolving shaft: POM;

 >> Specification
* Actuator motor: Reversible synchronous motor
* Power supply: AC220V, AC110V, AC24V
* Output torque: 5N.m
* Control way: on/off or 3-piont
* Media temperature range: 2°C~90°C
* Running time: 16S/50Hz, 12S/60Hz
* Power consumption: <5W
* Pipe Connection: G/BSP
* Ambient temperature: -5°C~60°C
* Ambient humidity: <90%
* Pressure grade: PN20
* Protect rank: IP54


 >> Model Table

 >> Dimensions

 >> Application

 >> FAQ
