HTW-V61 series motorized valves(3-wire) are used to control the flow of hot water, chill water in heating, cooling or air-conditioning applications, so as to control room temperature indirectly. It consists of Actuator and Valve Body. The room temperature could be controlled in the set-point through turn-on or turn-off of valve.
Alta calidad Htw-V61 24/110/220 VAC Válvula de latón para el control de agua del calentador
>> General
HTW-V61 series motorized valves(3-wire) are used to control the flow of hot water, chill water in heating, cooling or air-conditioning applications, so as to control room temperature indirectly. It consists of Actuator and Valve Body. The room temperature could be controlled in the set-point through turn-on or turn-off of valve.
>> Technical Parameters
-Consumo 5W
-Estilo de accionamiento Motor reversible bidireccional
-Tiempo de cooperación con termostato la válvula se abre en 6s a 60HZ
-N.W.(Kg)-Actuador 0.35
-Agua fría/caliente media
-Temperatura del líquido 1~95°C
-Presión(MPa) 1,6
-Temperatura ambiente 0~65°C la humedad relativa máxima, sin condensación
-Temperatura de almacenamiento -20~65°C humedad relativa máxima, sin condensación
>> Models& Specifications of Valve Body
Model | Configuration | Kvs | Connection Type | Differential Pressure(MPa) |
HTW-V61-215 | normally closed two-way | 2 | G1/2 | 0.20 |
HTW-V61-220 | normally closed two-way | 3.2 | G3/4 | 0.10 |
HTW-V61-225 | normally closed two-way | 5.7 | G1 | 0.06 |
HTW-V61-315 | mixing three-way | 3.2 | G1/2 | 0.20 |
HTW-V61-320 | mixing three-way | 4.6 | G3/4 | 0.10 |
HTW-V61-325 | mixing three-way | 4.8 | G1 | 0.06 |
