Termostato inteligente Tuya Controlador de temperatura WiFi con sensor remoto

Identificación del producto : HTW-WF11-FC-2EW

Etiquetas del producto : termostato ambiente termostato fan coil termostato inteligente

Atributos del producto :

El termostato fan coil inteligente de la serie HTW-WF11-FC se utiliza ampliamente para mantener una temperatura ambiente ideal.

Descripción del producto

Termostato inteligente Tuya Controlador de temperatura WiFi con sensor remoto

>> General

El termostato de ambiente FCU serie HTW-WF11-FC se utiliza ampliamente en el sistema Fan Coil Unit para controlar los ventiladores y las válvulas de zona motorizadas del aire acondicionado centralizado de calefacción/refrigeración.

>> Ordering Guide

HTW-WF11-FC-**	-2	2 pipe(tube) system
FCU Room Thermostat	-4	4 pipe(tube) system
	-M	0~10V Modulating Valve Output
	-N	RS485 Modbus RTU communication
	-K	Key Card occupancy input
	-W	WiFi Connection
	-E	External Temperature Sensor
	-24v	Power Supply with 24Vac
e.g. HTW-WF11-FC-2KE refers to application: 2 pipe(tube) system, 3 fan speed + 1 H/C valve, with key card and external sensor.

>> Specifications

Power Supply	95~240Vac, 50/60Hz	Sensor	NTC3950, 10K
Current Load	Fan Relay 5A(3A-inductive)	Temperature Accuracy	±0.5°C or ±1℉
Current Load	Valve Relay 3A(1A-inductive)	Set-Point Range	5~35°C
Storage Temp.	-5 ~ 45 °C	Display Temp. Range	5 ~ 99°C
Power Consumption	< 1.5W	Timing Error	< 1%
Housing Material	PC +ABS ( Fireproof)	Installation Box	EU or Standard Electric Box
Protection Class	IP20	Operating Buttons	Capacitive Touch Buttons
