Central Heating Furnace Forced Air System Compatible Best Home Thermostat
Central Heating Furnace Forced Air System Compatible Best Home Thermostat Central Heating Furnace Forced Air System Compatible Best Home Thermostat Central Heating Furnace Forced Air System Compatible Best Home Thermostat Central Heating Furnace Forced Air System Compatible Best Home Thermostat Central Heating Furnace Forced Air System Compatible Best Home Thermostat

Central Heating Furnace Forced Air System Compatible Best Home Thermostat

Product ID : HTW-ST01-B
Product Tags :
Product Attributes :

1 Heat / 1 Cool single stage thermostat.

5+2 Programmable, Compatible with heat pump system

This thermostat is compatible with the following systems:

 Gas, oil, Propane or electric furnace

 Central air conditioner

 Geo Thermal / Hot water system with or without pump

 Millivolt system

 Central heating and cooling system

 Heat pump without auxiliary/backup heat

 Forced Air / In-Floor Radiant / Radiator system



Product Description

programmable heat pump thermostat.jpg

>> General                                                eneral

1 Heat / 1 Cool single stage thermostat.

5+2 Programmable, Compatible with heat pump system

This thermostat is compatible with the following systems:

 Gas, oil, Propane or electric furnace

 Central air conditioner

 Geo Thermal / Hot water system with or without pump

 Millivolt system

 Central heating and cooling system

 Heat pump without auxiliary/backup heat

 Forced Air / In-Floor Radiant / Radiator system


>> Feature

• ºF or ºC configurable, Child Lock Function, Large LCD display, Backlight.

 Heat and Cool set point storage, 5+2 Programmable

 Display of room temperature, set temperature and current time simultaneously.

 Fan switch ON and AUTO.

 Permanent user setting retention during power loss. No batteries are required.

 Apply to 24VAC or 2 *AA alkaline batteries power supply.

 Air Filter change Indicator, Low Battery Indicator, Temperature calibration.

 4- or 5-wire compatible (C is optional for non-heat pump systems)

 Manual Changeover / Fan Switch, Easy operation friendly.

 Mercury-Free, Environmentally Safe

 Built-in compressor protection, IC= Intelligence Energy Management Recovery (EMR) Function

>> Specification


Power   Supply

20VAC-30VAC   50-60HZ or Battery powered.

Terminal Load

1.0A per terminal, 3.0A   maximum total load

Set Point    Temp. Range

45ºF to 90ºF (7ºC to   32ºC).

Accuracy

+/- 1ºF or +/- 0.5ºC.

Dimensions

6.0” W X 4.7” H X 1.1” D/152.5x120x28mm

Color

White

Installation Hole Distance

3.37”/85.5mm Horizontal and 3 1/4(83 mm)Vertical

or   2.36”/60mm Horizontal



>> LCD Display





>> Company Profile

Hotowell is a high-tech company with rich experiences in product design and manufacturing, knowledge about global HVAC standards, and highly-trained team.

Our objective is to produce and design user-friendly HVAC products on the highest technical level for improving people's experience in temperature/environment comfort.
Hotowell has been cooperating with many international companies and HVAC projects through Europe, American, Asia, Oceania.  Our product range contains:
Thermostats, Motorized Zone Valves, Ball Valves, Valve Actuators, Damper Actuators, Controllers, Radiator valves, and etc.

covering industrial, commercial and residential temperature controls.



>> FAQs

Q1:What is the unit price?
A.:The unit price varies according to different specific requirements, we are more than pleased to quote you the best price once get your specific application. e.g. W/O Modbus, W/O key-card, 2/4 pipe system, W/O customized programming...
Anyway, we are always ready to discuss details with you via Email.


Q2:What is the MOQ, small quantities accetaple?
A.: Commonly the MOQ for us is 500pcs, however, we also accept small quantities or Sample orders as starting.

Q3:How is your products' quality and warrenty?
A.:All of our products meet EU standards, samples are available for quality evaluation; all products are with 18 months warrenty.


Q4:Can I print my logo on the products, and customize my own designed packing?
A.:100% YES, but the order quantity shall be over MOQ, or else, extra costs will be charged.

Q5:Do you supply OEM or ODM?
A.:Yes, we have strong R&D sources and production ability, and already helping many international companies OEM/ODM cases with highly positive feedback.

Q6:Why should I buy products from your company?
A.:That's really a good question, Quality Products but with Competitive Price, Timely Delivery, Professional and Fast Reacton, ...
In a word, WE ARE DIFFERENT, why not just try from the Email...
