Wireless Window/Door Contact Switch Application
Wireless Window/Door Contact Switch Application Wireless Window/Door Contact Switch Application Wireless Window/Door Contact Switch Application Wireless Window/Door Contact Switch Application Wireless Window/Door Contact Switch Application

Wireless Window/Door Contact Switch Application

Product ID : HTW-YM-XB
Product Attributes :

n  Power voltage:DC6V (CR2016 3V * 2PCS)

n  Quiescent current: ≤8uA

n  Working current: ≤10mA

n  Working frequency: 433.92Mhz

n  Working indicator: Red LED

n  Low battery: blue LED, blink every 2s

n  Low battery: 4.4V ±5%.

Product Description


Wireless Window.Door Contact Switch Application-R.pdf

 Model:HTW-YM-XB

n  Power voltage:DC6V (CR2016 3V * 2PCS)

n  Quiescent current: ≤8uA

n  Working current: ≤10mA

n  Working frequency: 433.92Mhz

n  Working indicator: Red LED

n  Low battery: blue LED, blink every 2s

n  Low battery: 4.4V ±5%.

Signal coding based on chip EV1527.

Contact Closed: code 1010

Contact Open:Code 0111

i.e. it sends 2 different signal to receiver to detect the window/door is open or closed.

Wireless Window Door Contact (2).jpg

*Recommend match with Receiver: HTW-RV-U22

 Please Remove the Plastic Plate on Button Battery Before Using.

 Model:HTW-RV-U22

n  Power voltage:100-240Vac, 50/60Hz

n  Output: Non-Voltage dry contact

n  Quiescent current: ≤7mA

n  Working frequency: 433.92Mhz

n  Reed Switch instead of Relay optional

n  Effective Distance:50M without walls

n  Size: 88 x 38 x 22mm


Learn code and Remove Code

1.Open the cover shell

2.Clear the memory :press the learning button about 10 seconds , the indicator turn on to off , it means the Code had been removed successfully.

3. Learn: press the LRN learning button, the indicator from on to off , loosen your finger, then open the wireless contact, the indicator flash 2 times and off .it mean you learn the wireless contact successfully .

 >> Application
